Note
Commenting out spindle SPOS commands
If the spindle SPOS command is to be commented out in the CUST_MEACYC.SPF cycle, set
the cycle setting in SD55740 $SCS_MEA_FUNCTION_MASK to active with Bit 1 = 1.
You can see how to comment out a spindle SPOS command in the CUST_MEACYC.SPF
cycle in the following example:
Example
;
;*#1 Example application for spindle pre-positioning if there is no coupling
;*##1 between spindle and the coordinate system active!
;*#1 This example can be removed if necessary!
;*#2 User example for spindel positioning, if you do not have a coupling
;*##2 between the spindel and the coordinate system!
;*#2 If this lines are not necessary, the user can delete this example!
;
; cycle is calling from the AUTOMATIC-mode AND the spindel is positionable
IF NOT(_OVI[14]) AND NOT(_SPOS_MOD)
; no coupling between the spindel and the coordinate system!
; SD55740, Bit 1 = 0
IF ($SCS_MEA_FUNCTION_MASK B_AND 'B10')==0
; SPOS=0 ; <===== commented out
ENDIF
ENDIF
M17
;
21.10.3 Measuring in JOG mode
Requirements
You have already made the settings from the previous Chapter "Measuring cycles and
measurement functions, general (Page 617)".
Technologies and cycles
21.10 Measuring cycles and measurement functions
SINUMERIK Operate (IM9)
Commissioning Manual, 12/2017, 6FC5397-1DP40-6BA1 623
