Activation
To activate the Display Manager, the following display machine data must be set.
MD9114 $MM_SIDESCREEN SINUMERIK Operate Sidescreen
= 2 Enables the Sidescreen display area in HD Ready.
Releases the Display Manager in Full HD.
The default configurations used by the Display Manager for the two screen resolutions,
1920x1080 and 1366x768, are in the two files:
● sldm_1920x1080.ini
● sldm_1366x768.ini
These files can be used as a template for custom display configurations. This section describes
how to create custom display configurations.
3.14.2 Creating your own display configurations
3.14.2.1 Displays
One or more displays can be defined in the respective configuration file for each display
configuration. A name and a list of frames are specified for each of these displays. The frames
describe the division of the display into rectangular areas in which applications or menus can
be displayed.
Example
[displays]
DISPLAY001= name:=display_1, frames:="frame1, frame2, frame3"
DISPLAY002= name:=display_2, frames:="frame4, frame5, frame6, frame7"
…
Property Meaning
name
Name of the display. Required, for example, for switching displays
frames
Contains a comma-separated list of frames that should be present on
this display to describe the layout of the display
enableMirrorMode
(true|false)
Activates (true) or deactivates (false) mirror mode for the display
When the mirror mode is activated, all frames of the display are dis‐
played mirrored horizontally when the setMirrorMode (true) function is
called. Otherwise, the appearance of the frames remains unchanged
after calling the setMirrorMode (true) function.
"true" is default.
onStartup
Contains a semicolon-separated list of actions to be performed when
the display first appears
The possible actions are described below.
onShow
Contains a semicolon-separated list of actions to be performed each
time the display fades
The possible actions are described below.
General settings
3.14 Display Manager
SINUMERIK Operate (IM9)
Commissioning Manual, 12/2017, 6FC5397-1DP40-6BA1 55
