● Motor temperature
● Measuring system 1 active / measuring system 2 active
The states for measuring system 1/2 have the following meaning:
Symbol Meaning
The position measuring system is active.
The position measuring system is parked.
- OR: -
The position measuring system is not configured.
The position measuring system is passive.
Procedure
1. Select the "Diagnostics" operating area.
2.
Press the menu forward key and the “Axis diag" softkey.
3. Select an overview using the "Select" field.
- OR -
Press the "Go to selection" softkey to select an overview.
18.2.1 Selecting axes and drives
To display certain enable signals and statuses of machine axes, you can arrange a selection
of all the axes and drives that are available in any sequence you wish.
Note
The following selection configurations have been previously defined, and cannot be changed
or deleted:
● All NC axes and drives
● NC axes
● Drives without NC axis assignment
Service and diagnostics
18.2 Displaying the Service overview
SINUMERIK Operate (IM9)
Commissioning Manual, 12/2017, 6FC5397-1DP40-6BA1 411
