Setting the manual tool function
MD22562 $MC_TOOL_CHANGE_ERROR_MODE Response when errors occur at tool
change.
Bit 1 = 1 Manual tools can be loaded.
Bit 2 = 1 Active D No. > 0 and active T No. = 0 generate an alarm message.
Active D No. > 0 and active D No. = 0 generate an alarm message.
Note
If, in machine data MD22562 $MC_TOOL_CHANGE_ERROR_MODE bit 2 = 1, then you have
the option, using a correction selection (D No.) in the program, to stop the machine until the
PLC signals that the tool change has been completed. To do this, machine data MD20270
$MC_CUTTING_EDGE_DEFAULT must be set to = 0.
12.2 Configuring the user interface
Configurable settings
The following settings can be configured:
● General settings
● Configure the tool lists
● Configure the list parameters
● Configure the tool types
● Configure the "Additional Data" window
● Configure the "New Tool - Favorites" window
● Configure the "New Tool" window
● Configuring the "New Multitool" window
● Configuring the "New Tool from Code Carrier" window
● Configuring the "New Tool from File" window
● Configure the default values for new tools
● Configure the "Details" window
● Assign names for magazines and magazine locations
● Configuring the "Assign Tooltips for Multitool Locations" window
● Assign names for magazine location types
● Assignment of magazines and magazine locations to channels
● Assignment of magazines to coordinate systems
● Disabling the softkey depending on filters
Tool management
12.2 Configuring the user interface
SINUMERIK Operate (IM9)
Commissioning Manual, 12/2017, 6FC5397-1DP40-6BA1 169
