= 4 Read access rights: Access level 4 (keyswitch 3), default value
= 3 Write access: Access level 3 (user)
21.10.3.4 Measuring without electronic probe in JOG
Measure workpiece
For manual measuring functions in the JOG operating mode, for which a rotating spindle is
required, the following applies:
● The channel state must be reset at the instant in time that the measured value is transferred.
● The spindle can be moved or positioned either using the T,S,M menu or using the bits in
DB3x.DBB30.
● The following preconditions apply when using the DB3x.DBB30 technology functions with
fixed speed:
Setting the machine data
MD10709 $MN_PROG_SD_POWERON_INIT_TAB [0] = 0 Setting data to be initialized
MD35035 $MA_SPIND_FUNCTION_MASK Bit 4 = 0
Bit 5 = 1
Spindle functions
SD43200 $SA_SPIND_S Speed setting value
Note
The entry in SD43200 $SA_SPIND_S is kept at power on.
With these settings, the spindle velocity for manual operation, which is set in SD41200
$SN_JOG_SPIND_SET_VELO, is no longer effective.
21.10.4 Measuring in the AUTOMATIC mode
Requirement
Software option
In order to use the "Measuring in AUTOMATIC" function, you require the software
option: "Measuring cycles"
You have already made the settings from Chapter "Measuring cycles and measurement
functions, general (Page 617)".
Technologies and cycles
21.10 Measuring cycles and measurement functions
SINUMERIK Operate (IM9)
634 Commissioning Manual, 12/2017, 6FC5397-1DP40-6BA1
