Error analysis
You have the option of initiating a fault analysis for the components involved. You obtain the
result of a such a diagnostics in the form of a fault message. The possible fault states and
causes are described in this fault message together with how to resolve the fault.
17.6.1 Displaying network adapters
The actual network adapters (system network X120, company network X130 or system
network ETH2 and company network ETH1) and their availability are displayed in a tree-like
structure in the "TCP/IP diagnostics" window.
Displaying the components
The following components are displayed in the window:
● The control is displayed at the topmost level.
● System network (X120 / ETH2) with configured operator stations with IP address
– Operator panels with IP address
– Machine control panels
– EKS
● Company network (X130 / ETH1) with
– Operator panels with IP address
– Machine control panels
– EKS
Components that cannot be accessed
If a component cannot be accessed, then it is marked using this symbol.
Input rights
Operator panels, which have input rights, have a green background.
Detailed view
You have the option to display the following information about a selected component.
TCU
● IP address
● SW version
● MCP index from the configuration
● TCU index from the configuration
● DNS name
● Resolution
Configuring the network
17.6 Station-related network diagnostics
SINUMERIK Operate (IM9)
382 Commissioning Manual, 12/2017, 6FC5397-1DP40-6BA1
