This file is located in the "/user/sinumerik/hmi/log" directory.
Note
The conversion is only made if the .ts file is newer than the associated .qm file.
13.2.6 Range of alarms
Number ranges of alarms
Numerical range Description SourceID SourceURL
000 000 ... 009 999 General alarms 0 (standard
NCU)
100 (1. NCU)
...
9999 (99. NCU)
/NCK
//configura‐
tion_spec. Designa‐
tion>//NCK
010 000 ... 019 999 Channel alarms
020 000 ... 029 999 Axis/spindle alarms
030 000 ... 039 999 Functional alarms General
040 000 ... 059 999 Reserved
060 000 ... 064 999 Siemens cycle alarms
065 000 ... 069 999 Cycle alarms user
070 000 ... 079 999 Compile cycles
Manufacturer and OEM
080 000 ... 084 999 Siemens cycles mes‐
sage texts
085 000 ... 089 999 User cycles message
texts
090 000 ... 099 999 Reserved
100 000 ... 129 999 System 10 000 /HMI
130 000 ... 139 999 OEM
140 000 ... 199 999 Reserved
200 000 ... 299 999 SINAMICS drive 0 /NCK
300 000 ... 399 999 Drive and I/O alarms
400 000 ... 499 999 General alarms 51 /PLC/PMC
500 000 ... 599 999 Channel alarms
600 000 ... 699 000 Axis/spindle alarms
700 000 ... 799 999 User area
800 000 ... 899 999 Sequencers/graphs
810 000 ... 810 009 System error messages 50
150 (1st NCU)
/PLC/DiagBuffer
//<configuration-spec.
Designation>/PLC/
DiagBuffer
900 001 ... 965 999 HMI PRO sl Runtime
966 000 ... 999 999 Reserved
Configuring alarms
13.2 Configuring alarm and message texts via alarm text files
SINUMERIK Operate (IM9)
274 Commissioning Manual, 12/2017, 6FC5397-1DP40-6BA1
