user directory
/ico1280 // icons in resolution 1280x1024
/ico1600 // icons in resolution 1600x1240
/lng // text files
/proj // EasyScreen configuring
/log // log files
/md // machine data views
/proj // EasyScreen configuring
2.2 Editing files
2.2.1 Editing the file at the controller
Use can use a copy of the sample file in order to make specific adjustments. Template files
are available in the following directories:
/siemens/sinumerik/hmi/template/cfg and /siemens/sinumerik/hmi/template/lng
Save the sample file in the "user" or "oem" directory - in the appropriate folder.
Note
As soon as the file is in the user-specific directory, the entries of this file have priority over the
Siemens file. If an entry is missing in a user-specific file, the corresponding entry from the
Siemens file is used instead.
You need to restart the operating software for the settings made in the file to take effect.
Precondition
● If you copy files, you require access level 1 (manufacturer).
● When assigning a new file name, ensure that only files with a maximum name length of 49
characters can be managed.
Copying / pasting / opening a file
1. Select the "Start-up" operating area.
2. Press the "System data" softkey.
The data tree is displayed.
3. For instance, on the NCU directory, "System CF card", under "siemens"
open the required directory (e.g. /sinumerik/hmi/template/cfg).
Principles of start-up
2.2 Editing files
SINUMERIK Operate (IM9)
24 Commissioning Manual, 12/2017, 6FC5397-1DP40-6BA1
