= 0 The best available mold making function is automatically used:
● Top Surface not active → Advanced Surface
● Top Surface active → Top Surface
= 1 The mold making function (Advanced Surface or Top Surface) can be selected in the input
screenform.
Bit 4 Display selection "Smoothing"
= 0 Do not display selection "Smoothing" in the screen form (corresponds to smoothing = yes)
= 1 Display selection "Smoothing" in the screen form
Extension in manufacturer cycle CUST_832.SPF
The following labels are provided in manufacturing cycle CUST_832.spf for Top Surface:
31 _M_TOP_SURFACE_FINISH:
Finishing with COMPSURF
32 _M_TOP_SURFACE_SEMIFINISH:
Semi-finishing with COMPSURF
33 _M_TOP_SURFACE_ROUGH:
Roughing with COMPSURF
The following G commands are programmed in labels 31 to 33:
SOFT
COMPSURF
G645
FIFOCTRL
UPATH
;FFWON
Depending on the machining type used, the following G commands of G group 59 are
programmed:
DYNFINISH
DYNSEMIFIN
DYNROUGH
21.10 Measuring cycles and measurement functions
21.10.1 Measuring cycles and measurement functions, general
Requirement
Two types of electronic probes are used for measuring:
● Probe to measure the workpiece
● Probe to measure the tool
The electronic probe must be connected to the NCU 7x0.
The electronic probe is called a measuring input in the following document.
Technologies and cycles
21.10 Measuring cycles and measurement functions
SINUMERIK Operate (IM9)
Commissioning Manual, 12/2017, 6FC5397-1DP40-6BA1 617
