References
Function Manual Basic Functions; W1: Tool offset, parameter CUTMOD:
● The CUTMOD NC function is activated when data set 2 is called in the NC program
(CYCLE800 align turning tool). This means that the cutting edge position or the tool
reference point is updated corresponding to the tool orientation:
● When calling a swivel data set for rotational operation in the NC program (CYCLE800 align
tool), the CUTMOD NC function is activated. The cutting edge position, tool angle, cut
direction and tool reference point are thus calculated in accordance with the current tool
orientation following the "Align tool" function.
21.7.5 Manufacturer cycle CUST_800.SPF
Function
During swiveling, all axis positions are approached using the CUST_800.SPF cycle. The call
is exclusively made from the swivel cycle CYCLE800 or from the cycles
E_TCARR (ShopMill) or F_TCARR (ShopTurn).
In cycle CUST_800.SPF, the function markers (_M2: to _M59) are prepared and documented.
Also refer to the following "Structogram CYCLE800".
There are extensions in the CUST_800.SPF cycle for the "Turning on milling machine" function,
see Chapter "Adaptations for CUST_800 (Page 608)".
Note
If you modify the CUST_800, ensure that the G commands of the G groups used are restored
at the end of the CUST_800 (versions S_G_1 to S_G_5!).
Parameter
CUST_800 (INT _MODE, INT _TC1, REAL _A1, REAL _A2, INT _TC2, REAL _T_POS)
_MODE A jump is made to markers _M2 to _M59
_TC1 Number of the swivel head/table
_A1 Angle of rotary axis 1
_A2 Angle of rotary axis 2
_TC2 Feed evaluation in percent (%) for swiveling in JOG mode and number of the new swivel
head/table when replaced in ShopMill
_T_POS Incremental position during retraction in the incremental tool direction (see marker _M44,
_M45)
Technologies and cycles
21.7 Swiveling
SINUMERIK Operate (IM9)
Commissioning Manual, 12/2017, 6FC5397-1DP40-6BA1 589
