7.6.5 Setting up and using SSH
You can use remote access to access devices from the PCU.
An SSH environment is preinstalled when the PCU base software for Windows 7 is installed.
You can log on with PuTTy.
You can use an SSH key to log on. A script for setting up the infrastructure on devices is
provided. However, for security reasons no previously generated keys have been stored.
Setting up remote access with SSH and key pair
The procedure for setting up users and using remote access is the same as the usual procedure
for remote access with SSH.
Table 7-7 Support with setting up remote access
Task Recommended application Storage path Help
Generate key pair PuTTy Key Generator C:\Program Files (x86)\PuTTy
\puttygen.exe
Online help in PuTTy
(Chapter
Public key for pasting into au‐
thorized_keys file
)
Set up infrastructure on devices Supplied script ssh_key_log‐
in.bat
C:\ProgramData\Siemens\Mo‐
tion Control\siemens\etc.
\ssh_key_login.bat
Call up the script via the prompt. To do
this, enter user name and file name of
the public key as the parameters.
Syntax:
ssh_key_login.bat <user
name> <public key>
Example:
ssh_key_login.bat username
publicKey.pub
Access devices via remote con‐
nection
PuTTy
C:\Program Files (x86)\PuTTy
\putty.exe
Online help in PuTTy
IP address of the PCU (factory setting):
● System network: 192.168.214.241
● Company network: IP address is
taken from the DHCP server
See also
Encryption via SSH protocol (Page 170)
Remote access (Page 165)
Service and diagnostics
7.6 Remote access
PCU Base Software (IM10)
Commissioning Manual, 12/2017, 6FC5397-1DP40-6BA1 169
