Commissioning the system
1.4 BIOS settings for PCU 50.3
PCU-Basesoftware (IM8)
Commissioning Manual, 02/2014, 6FC5397-1DP40-4BA0
33
BIOS settings for PCU 50.3
Overview
The BIOS of the PCU is preset in such a way that no changes are required. The date and
time can be set under Windows or the user interface.
Note
Changes in the BIOS
Your device configuration is preset for working with the software supplied with the unit.
You should only change the preset values if you have modified your device in any way, or if
a fault oc
curs when the unit is powered up.
1. Start the BIOS SETUP as follows:
Reset the device (warm or cold restart).
After the startup test, the following message appears:
Press < F2 > to enter SETUP or <ESC> to show boot menu
2. Press the F2 key as long as the BIOS prompt appears on the screen.
The BIOS main menu opens:
Figure 1-15 BIOS Main Menu (Example)
