SourceIDs 1 ... 10
The SourceIDs 1 ... 10 have the following relationship:
SourceID SourceURL
1 /NCK/Channel#1/Partprogram
2 /NCK/Channel#2/Partprogram
3 /NCK/Channel#3/Partprogram
4 /NCK/Channel#4/Partprogram
5 /NCK/Channel#5/Partprogram
6 /NCK/Channel#6/Partprogram
7 /NCK/Channel#7/Partprogram
8 /NCK/Channel#8/Partprogram
9 /NCK/Channel#9/Partprogram
10 /NCK/Channel#10/Partprogram
13.2.7 Parameter specifications in alarm texts
Alarm texts can contain alarm parameters (accompanying values) that specify the cause of an
alarm in more detail. These parameters are usually numerical values that are transmitted from
an alarm source when the alarm is signaled along with the other alarm data.
How the parameters are incorporated into the alarm text is specified via place holders
(parameter specifications) in the language-specific alarm texts, e.g. "Channel %1 Axis %2 in
machine data %3 defined for several channels".
When an alarm occurs, the text is replaced by the corresponding parameters, e.g. "Channel
5 Axis A3 in machine data 4711 defined for several channels".
Standard parameter specifications
The following table shows the standard parameter specifications:
Table 13-1 Standard parameter specifications
Parameter
specifier
Description
%1 First parameter from the alarm data of the alarm source.
%2 Second parameter from the alarm data of the alarm source.
%3 Third parameter from the alarm data of the alarm source.
%4 Fourth parameter from the alarm data of the alarm source.
%5 Fifth parameter from the alarm data of the alarm source.
Only for NCK alarms:
First part (up to the separator) of the fourth parameter from the alarm data of the alarm
source.
Configuring alarms
13.2 Configuring alarm and message texts via alarm text files
SINUMERIK Operate (IM9)
Commissioning Manual, 12/2017, 6FC5397-1DP40-6BA1 275
