If you press the "Peaks" softkey, the cursor only goes to the peak-peak
values.
If you press the "Minimum" softkey, the cursor only goes to the peak-valley
values.
18.13 PROFIBUS/PROFINET and AS-i bus diagnostics
18.13.1 PROFIBUS/PROFINET
With the PROFIBUS/PROFINET diagnostics, you obtain a quick overview from which, when
required, you can call status and detailed information for external DP master systems and
PROFINET IO systems.
Precondition for detailed diagnostics
When using HMI PRO RT, the diagnostics can be extended by additional information (e.g.
module and Order No.). This data involves offline data, which can be extracted from the
associated Step7 project.
● You can create offline data using the HMIPRO CS program.
● You transfer data to the control using the HMIPRO program.
Software option
For faulted modules, in order that in addition to the status information, detailed
information can also be displayed, you now require the following option:
"Operating software SW HMI PRO sl RT".
In order that detailed information can be displayed for PROFINET-IO systems, the PLC block
FB_SL_COM from the HMI PRO block library must be used. Use DB449 as the associated
instance DB.
Note
Detailed information for DP master systems is also available without using FB_SL_COM.
Diagnostics information from the DP master systems
You can configure the following versions:
1. Software option not available and HMIPRO offline data not available
2. Software option available and HMIPRO offline data not available
3. Software option available and HMIPRO offline data available
Service and diagnostics
18.13 PROFIBUS/PROFINET and AS-i bus diagnostics
SINUMERIK Operate (IM9)
476 Commissioning Manual, 12/2017, 6FC5397-1DP40-6BA1
