5.7 Example 5: Image display
Example 5
Displaying an image instead of a short text: The size and position of the image is defined under
"Position of input/output field (left, top, width, height)".
DEF VAR6= (V///,"\\image1.png" ////160,40,50,50)
Variable type: VARIANT
Texts:
Short text: image1.png
Position of input/output field:
Distance from left: 160
Distance from the top: 40
Width: 50
Height: 50
Variables
5.7 Example 5: Image display
SINUMERIK Integrate Run MyScreens (BE2)
88 Programming Manual, 12/2017, 6FC5397-1DP40-6BA1
