= 0 The "Clamp/release spindle" parameter is not displayed in the drilling and milling screens.
ShopTurn automatically clamps the spindle if it makes sense for the particular machining
operation.
= 1 The "Clamp/release spindle" parameter is displayed in the drilling and milling screens. The
operator decides for which machining operation the spindle should be clamped.
Note
The face end machining is automatically integrated in the cycles, with the exception of the
straight line and circle.
You can select the functions for these two cycles in the "Program" operating area at "Straight
line" and "Circle".
Additional information on end face machining is provided in:
References
Function Manual Extended Functions; M1: Kinematic transformation,
Section: "TRANSMIT face end transformation"
21.5.10 Inclined Y axis (TRAANG)
Software option
You require the following software option in order to use the inclined Y axis function
on your machine:
"Inclined axis"
Function
If your turning machine has an inclined Y axis (i.e. this axis is not perpendicular to axes X and
Z), you can still completely program machining operations in Cartesian coordinates. The
control uses the inclined axis function (TRAANG) to transform the Cartesian coordinates to
the motion of the inclined axis.
Setting up
You still have to set up the inclined axis function (TRAANG) via machine data.
Technologies and cycles
21.5 Turning
SINUMERIK Operate (IM9)
Commissioning Manual, 12/2017, 6FC5397-1DP40-6BA1 551
