[14] = 1 The current setting of the 15th G group is also retained after reset / part program end
(G94, ...).
[28] = 1 The current setting of the 29th G group is also retained after reset / part program end
(DIAMxxx).
Behavior at power on
In order to retain the kinematics transformation after a power on, you must also make the
following additional settings:
MD20144 $MC_TRAFO_MODE_MASK Selection of the kinematics transformation function
Bit 1 = 1 Reselection of the transformation after power-up
MD24008 $MC_CHSFRAME_POWERON_MASK Reset system frames after power on
Bit 4 = 0 Do not delete workpiece reference points after power on
Note
The CUTMODK function cannot be retained after power on.
21.8.4 Setting the tool clamping angle
If the clamped turning tool is not in the G18 plane at the spindle zero position, the clamping
angle must be set.
Procedure
1. Select the "Parameter" operating area.
2. Press the "Tool list" softkey.
The "Tool List" window opens.
3. Select a suitable turning tool in the list.
4. Press the "Additional data" softkey.
The "Additional Data - ..." window opens.
The "Additional data" softkey is only active if a turning tool for which the
"Additional Data" window is configured is selected.
5. Enter the required angle in the "Angle" input field.
Note
The clamping angle is stored in the $TC_DPROT cutting edge parameter.
Technologies and cycles
21.8 Turning on milling machines
SINUMERIK Operate (IM9)
606 Commissioning Manual, 12/2017, 6FC5397-1DP40-6BA1
