You can define the following parameters in the "Magazine" window from the loading magazine
directory:
Parameters Description
Name Designation of the loading magazine
The designation is displayed in the tree structure.
Magazine number 9999 (cannot be changed)
Locations Number of loading locations
Element values
You can change the loading location type with the parameters in the "Location" window:
Parameters Description
(Selection menu) Select a loading location type:
● Load location
Load locations are areas on the machine at which the direct loading
in the magazine is possible. The tool can be inserted directly into
the magazine at this location. The magazine location to be loaded
is moved to the loading point. For example, chain magazines have
loading points.
● Loading station
A loading station is a location outside the magazine onto which the
tool to be loaded is placed. The tool is then transported from that
location to the magazine via a transport mechanism. Loading
stations are generally used for box or chain magazines.
Index The index counts the locations of a type.
Note
Loading point 1 is always set automatically as loading/unloading point for spindle 1 (manual
loading point).
12.6.3.4 Create magazine configuration
You can define several magazines in a tool unit. You define the magazine configuration via
the "Magazine" window. The magazine location type is defined from the "Location" window.
Directory values
You are currently located under the "Active data" → <tool unit> → <magazine> directory in the
"Commissioning" → "NC" →"Tool management" operating area.
Tool management
12.6 Editor for the tool and magazine management
SINUMERIK Operate (IM9)
250 Commissioning Manual, 12/2017, 6FC5397-1DP40-6BA1
