2.7 Script language
Note
All script elements described in the Generating user dialogs (Page 5) function form the basis
for the "Easy Extend" function. Additional script elements are defined to manage additional
devices.
Program parts of the script
The script is divided into the following areas:
● "Easy Extend" identifier
● Frame to define the actions that can be executed for a device
● Identifier for the device
● Identifier for commissioning the device
● Identifier for activating the device
● Identifier for deactivating the device
● Identifier for testing the device
● Identifier for the parameter dialog
The individual tags are described in the following chapters.
Description
Identifier <tag> Meaning
AGM Identifier for the "Startup Wizard"
DEVICE
Identifier for the description of the device.
Attributes:
● option_bit
The device is assigned a fixed bit number for the option
management.
NAME The identifier specifies the name of the device to be displayed in the
dialog.
If a text reference is used, the dialog displays the text which is saved
for the identifier.
START_UP The identifier contains a description of the sequences required for
commissioning the device.
Generating commissioning dialogs
2.7 Script language
Easy XML
Programming Manual, 12/2017, 6FC5397-1DP40-6BA1 187
