MD54740 $SNS_MEA_FUNCTION_MASK Measuring cycles function screen
Bit 0 Workpiece, repeat measurement if TSA, TDIF exceeded
Bit 1 Workpiece, repeat measurement with M0 if TSA, TDIF exceeded
Bit 2 Workpiece, stop at M0 if TUL, TLL exceeded
Bit 3 Workpiece, accept calibrated probe sphere radius in tool data
Bit 4 Workpiece, plane can vary between calibration and measurement
Bit 16 Tool, repeat measurement if TDIF, TSA exceeded
Bit 17 Tool, repeat measurement with stop at M0 if TDIF, TSA exceeded
Bit 19 Tool, milling, reduction of spindle speed during last probing
MD55740 $SCS_MEA_FUNCTION_MASK Measuring cycles function screen
Bit 0 Workpiece, collision monitoring for intermediate positioning
Bit 1 Workpiece, coupling of spindle position with coordinate rotation around the infeed axis
Bit 2 Workpiece, reverse positioning direction if spindle position is coupled
Bit 3 Workpiece, no repetition if probe does not switch
Bit 4 Workpiece, 1st probing for every measurement with rapid measuring feedrate
Bit 5 Workpiece, rapid retraction following measurement
Bit 6 Workpiece, deactivate probe during spindle positioning
Bit 7 Kinematics, scaling on the basis of the input values of the rotary axis vectors
Bit 8 Kinematics, measuring with swiveling (TCARR) or active TRAORI
Bit 9 Kinematics, user-specific scaling of the rotary axis vectors
Bit 10 Kinematics, measure completely with reference
Bit 11 Kinematics, number of measurement points when measuring calibration sphere
Bit 15 Workpiece, calibrating radius with starting point in center of ring, JOG mode only
Bit 16 Tool, collision monitoring for intermediate positioning
Bit 17 Tool, no repetition if probe does not switch
Bit 19 Tool, rapid retraction following measurement
Bit 28 Continuous measuring standard log in JOG (attach)
Bit 29 Table format for measuring standard log in JOG
21.10.2 Manufacturer and user cycle CUST_MEACYC.SPF
Function
The CUST_MEACYC.SPF is part of the measuring cycle functionality. It is called in every
measuring cycle before and after executing the measurement task. The CUST_MEACYC.SPF
acts in the same way when measuring in the JOG mode and measuring in the AUTOMATIC
mode.
Technologies and cycles
21.10 Measuring cycles and measurement functions
SINUMERIK Operate (IM9)
620 Commissioning Manual, 12/2017, 6FC5397-1DP40-6BA1
