SINUMERIK Operate on PC/PCU
23
23.1 Link OEMFrame application
Integrating an OEM application
The following files should be adapted and created in order to integrate an OEMFrame
application into the operating software:
● Configuration file "systemconfiguration.ini"
The operating software is started and controlled from the system manager; the system
manager also controls the OEMFrame applications. The system manager is configured
using the "systemconfiguration.ini" configuration file.
● Configuring the start softkey
In order to start an OEMFrame application from the operating software, configure a softkey
on the expansion bar of the operating area.
● Configuration file "slamconfig.ini"
In order to configure the softkey position with text and/or symbol for the OEMFrame
application, generate the "slamconfig.ini" file.
● Save the language-dependent text for a softkey in the file mytext_<Ing>.ts.
"systemconfiguration.ini" file
In order to integrate an OEMFrame application into the operating software, copy the
"systemconfiguration.ini" configuration file and place it in one of the two directories:
<Installation path>/user/sinumerik/hmi/cfg
<Installation path>/oem/sinumerik/hmi/cfg
All of the processes to be managed by the system manager, as well as the applications that
are to be integrated as OEMFrame applications are in the [processes] section.
Value Meaning
process
Symbolic name of the OEMFrame application. This is required to configure the
operating areas.
cmdline
Command line which is transferred to the "oemframe.exe" process when starting.
oemframe
For OEMFrame applications, always set to "true".
windowname
Window name of the OEMFrame application - determined with "findwindow.exe".
classname
Class name of the OEMFrame application - determined with "findwindow.exe".
deferred
true: OEMFrame application is not started when SINUMERIK Operate powers
up, but only when selected for the first time.
SINUMERIK Operate (IM9)
Commissioning Manual, 12/2017, 6FC5397-1DP40-6BA1 659
