MD32310 $MA_MAX_ACCEL_OVL_FACTOR[0..4] Overload factor for axial velocity
jumps.
MD32431 $MA_ MAX_AX_JERK[0..4] Maximum axial jerk for path mo‐
tion.
MD32432 $MA_PATH_TRANS_JERK_LIM[0..4] Maximum axial jerk at the block
transition in continuous-path
mode.
Note
During the optimization of the machine axes, the values (note array index) of the specified
machine data must be set correctly.
Machining type, deselection
When CYCLE832 is deselected, the G groups are programmed for the settings during the
program run time; these settings are declared in machine data
MD20150 $MC_GCODE_RESET_VALUES[ ]. This involves the G groups 1, 4, 10, 12, 21, 24,
30, 45, 59, 61.
The contour and orientation tolerance is deactivated (CTOL=-1, OTOL=-1).
21.9.2 Manufacturer cycle CUST_832.SPF
Function
In contrast to the settings (G functions) by CYCLE832.SPF, these settings can be modified in
the manufacturer cycle CUST_832.SPF.
The following markers are prepared in CUST_832.SPF:
_M_NORM:
For deselection _OFF CYCLE832
_M_FINISH:
For finishing _FINISH and _ORI_FINISH
_M_SEMIFINISH:
For semi-finishing _SEMIFIN and _ORI_SEMIFIN
_M_ROUGH:
For roughing _ROUGH and _ORI_ROUGH
The following G functions are programmed in CUST_832.SPF:
SOFT
COMPCAD
G645
FIFOCTRL
UPATH
;FFWON
Dependent on the machining type:
DYNNORM
DYNFINISH
DYNSEMIFIN
DYNROUGH
Technologies and cycles
21.9 High-speed machining
SINUMERIK Operate (IM9)
614 Commissioning Manual, 12/2017, 6FC5397-1DP40-6BA1
