Only programming G code programs
If the job list only contains G code programs, then you can deactivate the "multi-channel data"
function. To do this, set the following machine data:
MD51228 $MNS_FUNCTION_MASK_TECH Cross-technology function mask
Bit 0 G code programming without multi-channel data
= 1 Multi-channel data are not listed for job lists that only contain G code programs. The "multi-
channel data" softkey is not displayed.
8.10 Manual machine
General information
"Manual machine" allows you to work with large cycles in manual mode without having to write
programs especially for this purpose.
Software option
You require the following software option in order to use this function:
"ShopMill/ShopTurn"
Activation
MD52212 $MCS_FUNCTION_MASK_TECH Cross-technology function mask
Bit 8 Manual machine (ShopMill/ShopTurn)
Enables
MD52214 $MCS_FUNCTION_MASK_MILL Milling function screen
Bit 5 Enable spindle control, tool spindle
= 0 via the NC/PLC interface
= 1 via the user interface
Bit 6 Enable spindle control, rotating spindle
= 0 via the NC/PLC interface
= 1 via the user interface
MD52218 $MCS_FUNCTION_MASK_TURN Turning function screen
Bit 3 Enable spindle control, main spindle
= 0 via the NC/PLC interface
= 1 via the user interface
Bit 4 Enable spindle control, counterspindle
= 0 via the NC/PLC interface
= 1 via the user interface
Customizing the "Machine" operating area
8.10 Manual machine
SINUMERIK Operate (IM9)
Commissioning Manual, 12/2017, 6FC5397-1DP40-6BA1 129
