Identifier.sc = Signal color (sc: signal color)
Identifier.st = Short text (st: short text)
Identifier.tg = Toggle symbol (tg: toggle)
Identifier.tt = Tooltip (tt: tooltip
Identifier .typ = Variable type (typ: type)
Identifier.ur = Update rate (ur: update rate)
Identifier.ut = Unit text (ut: unit text)
Identifier.val = Variable value (val: value)
Identifier.var = System or user variable (var: variable)
Identifier.vld = Variable status (vld: validation)
Identifier.wr = Input mode (wr: write)
See also
Extended configuration syntax
(Page 36)
5.11 Details on the variable type
Variable type INTEGER
The following extensions for determining the display in the input/output field and the memory
utilization are possible for the "INTEGER" type:
2nd character in the extension data type
Display format
B Binary
D Decimal signed
H Hexadecimal
No data Decimal signed
3rd and/or 4th character in the extension data type
Memory utilization
B Byte
W Word
D Double word
BU Byte, Unsigned
WU Word, Unsigned
DU Double word, Unsigned
Variables
5.11 Details on the variable type
SINUMERIK Integrate Run MyScreens
Programming Manual, 10/2015, 6FC5397-3DP40-5BA3 75
