MD24805 $MC_TRACYL_ROT_AX_FRAME_1 Axial offset of the rotary axis is taken into
account during TRACYL.
= 2
MD24810 $MC_TRACYL_ROT_SIGN_IS_PLUS_1 Sign of the rotary axis for the 1st TRACYL
transformation
= 1
MD24820 $MC_TRACYL_BASE_TOOL_1[ ] Vector of the base tool for the 1st TRACYL
transformation.
[0] = 0
[1] = 0
[2] = 0
7.5.10 End face machining (TRANSMIT)
Software option
You require the following software option in order to use this function:
"Transmit and peripheral surface transformation"
Function
The end faces of a turned part are machined with the end face machining function
(TRANSMIT).
Setting up
For general settings for transformations, please refer to Chapter "
Cylinder surface
transformation (TRACYL) (Page
122)".
You can make additional settings in the following channel-specific machine data:
MD24100 $MC_TRAFO_TYPE_1 End
face
machining, main spindle: Trans‐
formation 1
= 256 Machining without Y1 axis
= 257 Machining with Y1 axis
MD24200 $MC_TRAFO_TYPE_2 End face machining, counterspindle:
Transformation 2
= 256 Machining without Y1 axis
= 257 Machining with Y1 axis
Configuring cycles
7.5 Turning
SINUMERIK Operate
Commissioning Manual, 10/2015, 6FC5397-3DP40-5BA3 125
