Reference lists
A
A.1 Lists of start softkeys
A.1.1
List of start softkeys for turning
Program operating area for turning
HSK1 HSK2 HSK3 HSK4 HSK5 HSK6 HSK7 HSK8
Edit Drilling Turning Contour turn‐
ing
Milling Miscellane‐
ous
Simulation NC select
HSK9 HSK10 HSK11 HSK12 HSK13 HSK14 HSK15 HSK16
-- Straight-line
circle
(only for
ShopTurn)
-- -- Measure
workpiece
Measure tool OEM --
Turning
The following tables list the possible start softkeys for turning technology. Assignments of
individual start softkeys can differ depending on the particular system. The specified OEM
softkeys are permitted for "Run MyScreens".
programGUIDE (G-Code) start softkeys:
Drilling Turning Contour turning Milling Miscellaneous
HSK2 HSK3 HSK4 HSK5 HSK6
VSK1 Centering Stock remov‐
al
Contour -- Face mill‐
ing
Contour Settings High
speed
settings
VSK2 Drilling ream‐
ing
Groove Stock removal -- Pocket Path Swivel plane Parallel
axes
VSK3 Deep-hole drill‐
ing
Undercut Stock remov‐
al
residual ma‐
terial
-- Multi-edge
spigot
Predrilling Swivel tool --
VSK4 Boring Thread Grooving -- Groove Pocket -- --
VSK5 Thread Parting Grooving re‐
sidual
material
-- Thread
milling
Pocket
res. mat.
-- --
VSK6 OEM -- Plunge-turn‐
ing
-- Engraving Spigot Subprogram --
SINUMERIK Integrate Run MyScreens
Programming Manual, 10/2015, 6FC5397-3DP40-5BA3 199
