5.5 Terminal assignments
5.5.1
Terminal assignment at X122 and X132
X122: Digital inputs/outputs of the PPU
Pin Signal name
Status Meaning
1
DI0
DI0 r722.0 Digital input 0
2 DI1 DI1 r722.1 Digital input 1
3 DI2 DI2 r722.2 Digital input 2
4 DI3 DI3 r722.3 Digital input 3
5 DI16 DI16 r722.16 Digital input 16
6 DI17 DI17 r722.17 Digital input 17
7 M2 MEXT2 --- Ground for pins 1...6
8 P1 P24EXT1 --- +24 V power supply
9 IO8 DI/DO8 r722.8 / r747.8 Digital input/output 8
10 IO9 DI/DO9 r722.9 / r747.9 Digital input/output 9
11 M1 MEXT1 --- Ground for pins 9, 10, 12, 13
12 IO10 DI/DO10 r722.10 / r747.10 Digital input/output 10
13 IO11 DI/DO11 r722.11 / r747.11 Digital input/output 11
14 M1 MEXT1 --- Ground for pins 9, 10, 12, 13
X132: Digital inputs/outputs of the PPU
Pin Signal name Status Meaning
1 DI4 DI4 r722.4 Digital input 4
2 DI5 DI5 r722.5 Digital input 5
3 DI6 DI6 r722.6 Digital input 6
4 DI7 DI7 r722.7 Digital input 7
5 DI20 DI20 r722.20 Digital input 20
6 DI21 DI21 r722.21 Digital input 21
7 M2 MEXT2 --- Ground for pins 1...6
8 P1 P24EXT1 --- +24 V power supply
9 IO12 DI/DO12 r722.12 / r747.12 Digital input/output 12
10 IO13 DI/DO13 r722.13 / r747.12 Digital input/output 13
11 M1 MEXT1 --- Ground for pins 9, 10, 12, 13
12 IO14 DI/DO14 r722.14 / r747.14 Digital input/output 14
13 IO15 DI/DO15 r722.15 / r747.15 Digital input/output 15
14 M1 MEXT1 --- Ground for pins 9, 10, 12, 13
Commissioning the drive
5.5 Terminal assignments
CNC commissioning
146 Commissioning Manual, 10/2015, 6FC5397-3DP40-5BA3
