Identifier Parameter or property System variable
*)
ToolMaxAcc Maximum acceleration $TC_TP_MAX_
ACC
ToolInMultiTool Multitool in which the tool is located $A_TOOLMTN
ToolInMultiToolPlace Multitool location containing the tool $A_TOOLMTLN
ToolMyMultiTool Owner multitool of the tool $A_MYMTN
ToolMyMultiToolPlace Owner multitool location of the tool $A_MYMTLN
ToolAlarmIsExtended PLC tool status - function "extended alarm" ac‐
tive
-
ToolAlarmLimit PLC tool status - alarm limit reached -
ToolExtAlarmLimit PLC tool status - limit "extended alarm" reached -
ToolUser_1, ... ToolUser_10 OEM tool parameters 1 to 10 $TC_TPC1, ...
$TC_TPC10
ToolAppl_1, ... ToolAppl_10 Siemens application tool parameters 1 to 10 $TC_TPCS1, ...
$TC_TPCS10
*)
Parameter corresponds to the
system variable or the system variable is the basis for this parameter.
Note
Tool name "ToolIdent"
The maximum length of tool names is 31 ASCII characters.
The number of characters is reduced for Asian characters or Unicode characters.
The following special characters are not permitted: | # "
9.2.2.2 Cutting parameter identifiers
For the cutting parameters, the following identifiers are used in the configuration file:
Identifier Parameter or property System variable
*)
EdgeNo D number -
EdgeNoIdx Cutting edge number -
ToolType Tool type, cutting parameter 1 $TC_DP1
CuttEdgePos Cutting edge position, cutting parameter 2 $TC_DP2
GeoLength1 Length 1, cutting parameter 3 $TC_DP3
GeoLengthGeoAx1 Length of geometry axis 1, cutting parameter 3, e.g.
length X
$TC_DP3
GeoLength Length, cutting parameter 3 $TC_DP3
GeoLength2 Length 2, cutting parameter 4 $TC_DP4
GeoLengthGeoAx3 Length of geometry axis 3, cutting parameter 4, e.g.
length Z
$TC_DP4
GeoLength3 Length 3, cutting parameter 5 $TC_DP5
GeoLengthGeoAx2 Length of geometry axis 2, cutting parameter 5, e.g.
length Y
$TC_DP5
GeoRadius Radius, cutting parameter 6 $TC_DP6
GeoCornerRadius Corner radius, cutting parameter 7 $TC_DP7
Tool management
9.2 Configuring the user interface
SINUMERIK Operate
242 Commissioning Manual, 10/2015, 6FC5397-3DP40-5BA3
