- OR -
Press the "OK" softkey to save the network configuration.
4.4 Station-related network diagnostics
With the aid of the station-related network diagnostics, you can find and examine faulty,
incorrectly parameterized or unconnected network and bus interfaces.
The network/bus interfaces of the SINUMERIK 828D are:
●
Company network (X130)
● Service (X127)
● PROFINET (PLC I/O interface PN1, PN2)
●
PROFIBUS (integrated)
4.4.1 Displaying the PPU network interfaces
The network interfaces, e.g. company network X130 and service X127, and their availability
are displayed in a tree topology in the "TCP/IP Diagnostics" window.
Detailed view
You can display detailed information about a selected interface, e.g. IP address, DNS name,
etc.
Procedure
1. Select the "Diagnostics" operating area.
2. Press the menu forward key and the "Bus TCP/IP" softkey.
3. Press the "TCP/IP diagnostics" softkey.
The "TCP/IP Diagnostics" window opens and displays the current avail‐
ability of the network connections.
4. Position the cursor on the interface for which you wish to display the
detailed information.
5. Press the "Details" softkey to display all available parameters of the con‐
figured network connections.
Configuring the network
4.4 Station-related network diagnostics
SINUMERIK Operate
40 Commissioning Manual, 10/2015, 6FC5397-3DP40-5BA3
