SD55506 $SCS_TURN_ROUGH_I_RELEASE_DIST Retraction distance for stock remov‐
al during internal machining
= 0.5 Specifies the distance, by which the tool is retracted from the contour when removing stock
from an internal corner. This does not apply to stock removal at a contour (default value).
= -1 The distance is internally defined.
7.5.4 Setting up a counterspindle
Software option
You require the following software option in order to use the counterspindle on your
machine:
"Generic coupling 'CP-STATIC'" or higher
Function
If your turning machine has a counterspindle, you can machine workpieces using turning,
drilling and milling functions on the front and rear faces without reclamping the workpiece
manually.
Before machining the rear face, the counterspindle must grip the workpiece, pull it out of the
main spindle, and position it at the new machining position.
Meaning of the axes
MD52206 $MCS_AXIS_USAGE[n] Meaning of the axes in the channel
[n] channel axis number
A detailed description of MD52006 is provided in Chapter "Activating turning/milling/drilling/
grinding technologies (Page 75)".
Traversing direction
In order that the user interface and cycles know in which direction the spindles and rotary axes
rotate, the following settings must be made.
You set the direction of rotation of an NC rotary axis via MD32100 $MA_AX_MOTION_DIR.
MD32100 $MA_AX_MOTION_DIR Traversing direction (not control direction)
-1 Direction reversal
0, 1 No direction reversal
Configuring cycles
7.5 Turning
SINUMERIK Operate
Commissioning Manual, 10/2015, 6FC5397-3DP40-5BA3 111
