Siemens SINUMERIK 828D Commissioning Manual

Axis/spindle test run
Drive:
Parameter/terminal Meaning
p0840 ON/OFF1
p0844 1. OFF2
p0845 2. OFF2
p0848 1. OFF3
p0849 2. OFF3
p0852 Enable operation
X21.3 (+24 V) and X21.4 (ground) EP terminals enable (pulse enable)
p0864 Infeed enable
p1140 Ramp-function generator enable
p1141 Ramp-function generator start
p1142 Setpoint enable
Infeed:
Parameter/terminal Meaning
p0840 ON/OFF1
p0844 1. OFF2
p0845 2. OFF2
p0852 Enable operation
X21.3 (+24 V) and X21.4 (ground) EP terminals enable (pulse enable)
See also
Further references on the drive:
● SINAMICS S120 Commissioning Manual
● Manual Booksize power units
5.5.5 Interconnections (dialog)
Interconnections
Each
drive unit contains a large number of interconnectable input and output variables as well
as internal control variables. The drive unit can be adapted to a wide range of requirements
using BICO technology (Binector Connector Technology).
Commissioning the drive
5.5 Terminal assignments
CNC commissioning
152 Commissioning Manual, 10/2015, 6FC5397-3DP40-5BA3
