Identifier Parameter or property System variable
*)
MultiToolPlaceStateEmpty Multitool location empty $TC_MTPP4, Bit1
MultiToolPlaceTNo Tool number of the tool in this multitool location $TC_MTPP6
MultiToolPlaceAdaptNo Adapter number $TC_MTPP7
MultiToolPlaceNo Multitool location number -
MultiToolPlaceUser_1, … Mul‐
tiToolPlaceUser_10
OEM multitool location parameters 1 to 10 $TC_MTPPC1, …
$TC_MTPPC10
MultiToolPlaceAppl_1, … Mul‐
tiToolPlaceAppl_10
Siemens application multitool location parame‐
ters 1 to 10
$TC_MTPPCS1, …
$TC_MTPPCS10
*)
Parameter corresponds to the system variable or the system variable is the basis for this
parameter.
9.2.3 Configuring list parameters
<PARAMETERCONFIGURATION> tag
In the <PARAMETERCONFIGURATION> tag, you have the following options:
1. Changing list parameters.
2. Creating new list parameters based on an existing parameter.
Changing list parameters
You can change all list parameters included in the system.
Tool parameter identifiers
(Page 240)
Cutting parameter identifiers (Page 242)
Monitoring parameter identifiers (Page 244)
Grinding parameter identifiers (Page 245)
Magazine location parameter identifiers (Page 246)
Magazine location adapter parameter identifiers (Page 247)
Multitool parameter identifiers (Page 247)
Multitool location parameter identifiers (Page 248)
Entries Meaning
HeadLine Column header. Text entered is displayed as a header.
Example: Text "Radius" is displayed as a header (default).
Tooltip Text that is displayed in the tooltip.
Example: Text "Geometry radius" is displayed in the tooltip (default).
ShortText Text if the parameter is displayed in the "More Data" window.
Example: Text "Rad." is displayed in the "More Data" window (default).
DetailsText Text, if the parameter is displayed in the "Details" window.
Example: Text "Radius" is displayed in the "Details" window (default).
Tool management
9.2 Configuring the user interface
SINUMERIK Operate
Commissioning Manual, 10/2015, 6FC5397-3DP40-5BA3 249
