You can replace the Siemens logo with your own logo.
Procedure:
1. Name your own logo "logo.png".
Note
The file name must not contain any lower case letters.
2. Save your own logo depending on the bitmap size, in one of the directories: /oem/sinumerik/
hmi/ico or /user/sinumerik/hmi/ico
Directory Bitmap size
/Ico640 122 x 19
/Ico800 160 x 24
/Ico1024 199 x 30
5.3 Configuring the display of the G-code groups
The "G-functions" pane is visible in the "Machine" operating area.
Up to a maximum of 16 G-code groups are displayed in this pane. Configure the
"slmagcodeconfig.ini" file accordingly to
determine which G-code groups should be displayed,
and where.
Configuring G-code groups
Section Meaning
Selected G groups This area is intended for operation of the controller in Siemens mode.
Selected G groups ISO
mode
This area is intended for operation of the controller in ISO mode.
Enter the G-code group and position as follows:
SelectedGGroupN = M
N Position where G-code group M will be displayed.
If you want to leave a position empty, omit the number (M), e.g. "SelectedGGroup1 = "
M The number of the G-code group to be displayed at position N
Structure of the file
[Selected G-Groups]
SelectedGGroup1 = 1
SelectedGGroup2 = 2
SelectedGGroup3 = 3
Customizing the "Machine" operating area
5.3 Configuring the display of the G-code groups
SINUMERIK Operate
50 Commissioning Manual, 10/2015, 6FC5397-3DP40-5BA3
