Procedure
1. The "S1 Spindle Diagnostics" window is open.
The "S1 Clamping System" window is open without the "S-Monitor" software option.
2. Press the "Clamping system" softkey.
The "S1 Clamping System" window opens and displays the acquired data.
3. Press the "Speed limitation" softkey to change the limit values for the speeds of the
clamping states.
The "S1 Speed Limitations" window opens.
4.
Press the "Change" softkey to enter the desired speed limits depending on the clamping
state.
Confirm with "OK".
8.4.9 Clamping system: Diagnostic statistics
This window displays the statistics for clamping operations and speed violations.
Statistical data Meaning
Number of correct clamping cycles Accumulated number of correct clamping cycles with or without
tool.
Correct clamping cycle means:
"Released" clamping state [3] →
"Clamped" clamping state [7, 8 or 10] → "Released" clamping
state [3]. A clamping cycle is considered to be correct when a
clamping and subsequent release operation are performed via
the appropriate clamping states (without "State return"). Starting
from one clamping state, the next clamping state that can be
reached must not be the previous state. There is no dependency
on time.
Clamping time (without tool) The time within a clamping operation between the clamping
states "Tool released" and "Clamped without tool".
● Within tolerance
Accumulated number of clamping operations without tool that
were within the specified time.
● Outside tolerance
Accumulated number of clamping operations without tool that
were outside the specified time.
● Specification
Factory specification of the time for the clamping operation with‐
out tool.
● Current
Measured time for the last performed clamping operation with‐
out tool.
Clamped (without tool) Diagnostics during the "Clamped without tool" clamping state.
● Speed violations
Accumulated number of events during which the spindle speed
was greater than the set limit as delivered.
Spindle function
8.4 Spindle diagnostics
SINUMERIK Operate
Commissioning Manual, 10/2015, 6FC5397-3DP40-5BA3 217
