9.8.3 Example: Acknowledgment steps (milling machine)
Constant transfer step table
Transfer step of to Comment
Magazine Loca‐
tion
Magazine Loca‐
tion
1
DB9900.DBW0
0 1 9998 2 New tool from magazine to gripper
1
Step ⑥ or ⑬
2
DB9900.DBW8
9998 9998 3
Step ⑥ or ⑨
3
DB9900.DBW16
9998 9998 1
Step ⑦ or ⑩
4
DB9900.DBW24
9998 3 0 2
Step ⑦ or ⑭
5
DB9900.DBW32
0 2 9998 1 Storage location of the old tool
6
DB9900.DBW40
0 1 9998 1 Magazine location with the new tool
to the changing point
Step ② or ⑫
7
DB9900.DBW48
-- -- -- --
Variable transfer step table
Transfer step of to Comment
Magazine Loca‐
tion
Magazine Loca‐
tion
101
DB9901.DBW0
1 n 9998 1 The variable location in Magazine 1
is positioned at the changing point
to the spindle.
102
DB9901.DBW8
-- -- -- --
n : here is the actual location number (n ≠ 0) to be
entered by the PLC user program in the variable
transfer table.
Tool management
9.8 Application example for milling machine
CNC commissioning
330 Commissioning Manual, 10/2015, 6FC5397-3DP40-5BA3
