Rounding the contour
SD55582 $SCS_TURN_CONT_TRACE_ANGLE Contour turning: Minimum angle for
rounding on the contour
= 5 Specifies the angle between the cutting edge and contour, above which for contour turning,
the contour is rounded in order to remove residual material (default value).
7.5.3 Setting-up ShopTurn cycles for turning
MD52210 $MCS_FUNCTION_MASK_DISP Function mask display
Bit 0 = 1 Dimension system for programs always in the basic system (default setting)
Bit 1 = 1 Face view when turning (default setting)
Bit 4 = 1 Display follow-on tool in the T,F,S window
MD52212 $MCS_FUNCTION_MASK_TECH Cross-technology function mask
Bit 2 Approach logic for stepped drill
Bit 3 Block search cycle for ShopMill / ShopTurn
= 0 The E__ASUP or F_S_ASUP cycles are not called in the block search cycle
PROG_EVENT.SPF
= 1 The E__ASUP (under ShopMill) or F_S_ASUP (under ShopTurn) cycles are not called in
the block search cycle PROG_EVENT.SPF
Bit 4 Approach logic using the cycle
Bit 5 The cycle for SERUPRO (CYCLE207) is called in the block search cycle
PROG_EVENT.SPF.
Bit 6 Work offset value WO cannot be entered
Bit 7 Identification of the end of tool lives in the program (ShopMill / ShopTurn)
Bit 8 Manual machine (ShopMill/ShopTurn)
Bit 9 Selection/deselection of the work offset using softkey
Bit 11 Deactivate position check for drilling and milling tools
Bit 12 Alarm at positive Z offset
MD52214 $MCS_FUNCTION_MASK_MILL Milling function screen
Bit 3 "Inner/rear" machining is enabled in the ShopTurn screens which themselves define the
machining plane.
Bit 4 If you have implemented the "Clamp/release spindle" function using the manufacturer
cycle CUST_TECHCYC.SPF, then using
this machine data, you can activate the "Clamp/
release spindle" parameter in the drilling and milling screens.
= 0 The "Clamp/release spindle" parameter is not displayed in the drilling and milling screens.
ShopTurn automatically clamps the
spindle if it makes sense for the particular machining
operation.
= 1 The "Clamp/release spindle" parameter is displayed in the drilling and milling screens.
You decide for which machining operation the spindle should be clamped.
Configuring cycles
7.5 Turning
SINUMERIK Operate
Commissioning Manual, 10/2015, 6FC5397-3DP40-5BA3 109
