MD20310 $MC_TOOL_MANAGEMENT_MASK Activates tool manager functions
= 4002H Minimum value
Bit 1 = 1 Tool manager and monitoring functions active
Bit 14 = 1 Automatic tool change for RESET and Start.
MD28082 $MC_SYSTEM_FRAME_MASK System frames (SRAM).
1 Default, cannot be changed
The following channel-specific machine data acts only if the system frame actual value setting
and scratching is set-up using the above mentioned machine data
MD28082 $MC_SYSTEM_FRAME_MASK, bit 0 = 1.
MD24006 $MC_CHSFRAME_RESET_MASK Active system frames after reset.
Bit 0 = 1 Reset response of the system frames or actual value setting.
MD24007 $MC_CHSFRAME_RESET_CLEAR_MASK Clear system frames on reset.
Bit 0 = 0 Clear response of the system frames on reset.
Note
If
you
create
the
conditions described in this section and you have set and checked the machine
setting data, then in JOG mode, you can measure a workpiece using a workpiece probe at a
milling machine!
In JOG mode, you can measure a tool using a tool probe at a milling machine or lathe!
A description is provided in the following chapters as to which settings you can make in order
to adapt measuring to the specific requirements of your particular machine.
7.9.3.1 Measuring workpieces at the milling machines
Measuring in the "Machine" operating area can be appropriately adapted to the specific
requirements using the
following channel-specific general machine data and channel-specific
cycle setting data.
General configuration machine data
SD55630 $SCS_MEA_FEED_MEASURE Measuring feedrate for workpiece meas‐
urement in AUTOMATIC and JOG
300 Default value
Configuring cycles
7.9 Measuring cycles and measurement functions
SINUMERIK Operate
178 Commissioning Manual, 10/2015, 6FC5397-3DP40-5BA3
