Siemens SINUMERIK 828D Commissioning Manual

7.4 Milling
7.4.1
General
All
settings
for
machine and setting data of the standard cycles are also applicable for milling
under ShopMill and turning under ShopTurn.
7.4.2 Technology cycles for milling
Milling function screen
SD52214 $SCS_function_MASK_MILL Milling function screen
Bit 0 Enable cylinder surface transformation (ShopMill)
Bit 1 List table to accept blank (on milling machines)
(This bit must only be set if the machine has a rotation axis and a fixed table for the blank
clamping.)
Bit 2 Special treatment of disc mill/saw with multi-edge
(For these tool types
the first engagement is selected so that the top edge of the tool touches
reference point Z0 exactly.)
Bit 3 Enable machining inside/outside (ShopTurn)
Bit 4 Enable clamp spindle (C-axis) (ShopTurn)
Bit 5 Enable spindle control of the tool spindle via user interface
Bit 6 Enable spindle control of the main spindle via user interface
SD55214 $SCS_FUNCTION_MASK_MILL_SET Milling function screen
Bit 0 Basic setting milling cycles in sync.
Bit 2 Depth calculation of the milling cycles, with or without safety clearance.
= 0 Depth calculation of the milling cycles is performed between the reference plane + safety
clearance and the depth.
= 1 Depth calculation is performed without including the safety clearance.
Bit 2 is effective in the following milling cycles: CYCLE61, CYCLE71, CYCLE76, CYCLE77,
CYCLE79, CYCLE899, LONGHOLE, SLOT1, SLOT2, POCKET3, POCKET4.
Contour milling (CYCLE63, CYCLE64)
SD55460 $SCS_MILL_CONT_INITIAL_RAD_FIN Finishing approach circle radius
The
radius
of
the
approach circle during the
finishing of contour pockets is affected.
= 0 The radius is selected so that at the starting point the safety clearance to the finishing allow‐
ance is maintained (default value).
> 0 The radius is selected so that at the starting point the value of this channel-specific setting
data to the finishing allowance is maintained.
Configuring cycles
7.4 Milling
SINUMERIK Operate
Commissioning Manual, 10/2015, 6FC5397-3DP40-5BA3 95
