Tool management
9
9.1 Machine data for tool management
9.1.1
Settings with/without magazine management
Setting without magazine management
Make the following settings if you are commissioning the tool management without NC
magazine management:
MD18080 $MN_MM_TOOL_MANAGEMENT_MASK Memory for the tool management is re‐
served step-by-step (SRAM).
= 13E
Bit 0 = 0 Do not provide tool management data.
Bit 1 = 1 Provide monitoring data.
Bit 6 = 0 Magazines not divided into wear groups.
Note
Machine data MD18080 can only be set for the technology variants cylindrical and surface
grinding.
MD20310 $MC_TOOL_MANAGEMENT_MASK Activating the tool management functions.
= 420EH
Bit 0 = 0 Magazine management inactive.
Bit 1 = 1 Monitoring functions of tool management active.
MD17530 $MN_TOOL_DATA_CHANGE_COUNTER Marking the changed tool data for HMI.
= 1FH
Bit 0 Tool status change.
Bit 1 Tool remaining unit quantity change.
Bit 2 Tool data change service.
Bit 3 Magazine data in the change service.
Bit 4 ISO data in the change service.
SINUMERIK Operate
Commissioning Manual, 10/2015, 6FC5397-3DP40-5BA3 221
