Siemens SINUMERIK 828D Commissioning Manual

6.3 Simultaneous recording overview
Software option
You require the option "Simultaneous recording (real-time simulation)"
for the "Simultaneous recording" function.
Software option
You require the "ShopMill/ShopTurn" option to display the tailstock
Software option
You require the "3D simulation 1 (finished part)" option
for the 3D representation of the simultaneous recording function.
During machining, the tool paths can be simultaneously recorded on the display of the
controller in a three-side view or 3D view. Workpiece graphics and views correspond to the
graphic simulation.
Note
To prevent an incomplete representation, you must activate the simultaneous recording prior
to the NC start.
Simulation and simultaneous recording
6.3 Simultaneous recording overview
SINUMERIK Operate
Commissioning Manual, 10/2015, 6FC5397-3DP40-5BA3 69
