5.10 Configuring the offset display
Configuring the screen display
The screen display for offset can be configured using the following channel-specific machine
data:
MD52210 $MCS_FUNCTION_MASK_DISP Function screen display
Bit 14 Display DRF offset under Machine
Bit 15 Display tool offset ($AA_TOFF) under Machine
5.11 Activate machining time recording
If you want to record and store the machining time in Automatic mode, you can make the
settings on the user interface.
You will find additional information about making these settings in the following document:
References
Universal/Turning/Milling/Grinding Operating Manual
● Section "Machining a workpiece" > "Settings for Automatic mode mode"
● Section "Machining a workpiece" > "Editing a program" > "Settings for the editor"
Switching on the time recording
To be able to make use of the function, the following machine data must be set:
MD18370 $MN_MM_PROTOC_NUM_FILES[1] Maximum number of log files
= 2
For OEM applications
MD18371 $MN_MM_PROTOC_NUM_ETPD_STD_LIST[1] Number of standard ETPD data lists
= 6 Number of standard data lists in the OPI module ETPD that are needed for Trace system
functions.
MD28300 $MC_MM_PROTOC_USER_ACTIVE[1] Activate logging for one user
= 1 For system functions
MD28302 $MC_MM_PROTOC_NUM_ETP_STD_TYP[1] Number of ETP standard event types
= 5 Number of standard event types in the OPI module ETP that are needed
Customizing the "Machine" operating area
5.11 Activate machining time recording
SINUMERIK Operate
Commissioning Manual, 10/2015, 6FC5397-3DP40-5BA3 63
