Bit 2 Workpiece measurement: M0 for tolerance alarms 62304 oversize, 62305 undersize, 62306
permissible dimensional difference exceeded
Bit 3 Accept calibrated workpiece probe radius in the tool data.
Bit 4 For turning-milling technology, the calibration/measuring plane is different.
Bit 16 Repetitive measurement: tool measurement after a dimensional difference has been fallen
below (parameter _TDIF) and or confidence range (parameter _TSA)
Bit 17 Repetitive measurement: tool measurement with alarm and cycle stop at M0
Bit 18 Workpiece measurement: M0, after the permissible dimensional difference has been ex‐
ceeded
Bit 19 Tool measurement, milling tool: Spindle speed reduction at the last probing
MD55740 $SCS_MEA_FUNCTION_MASK Measuring cycles function screen
Bit 0 Collision monitoring using workpiece probe for intermediate positioning
Bit 1 Coupling the spindle alignment with coordinate rotation in the active plane, for workpiece
measurement with multiprobe in the automatic mode
Bit 2 Direction of rotation of the spindle positioning for workpiece measurement regarding active
coupling of the spindle alignment with coordinate rotation in the active plane
Bit 3 For workpiece measurement, number of repeat measurements if the probe does not switch
Bit 4 Measuring feedrate for workpiece measurement
Bit 5 Retraction velocity from the measuring point for workpiece measurement
Bit 6 Workpiece measurement: probe activation/deactivation when positioning the spindle
Bit 7 Measure kinematics, scaling basis for the orientation vectors
Bit 8 Measure kinematics, measurement with active TRAORI or TCARR (CYCLE 800)
Bit 15 Workpiece measurement: calibration in the bore with known or unknown center point, meas‐
uring in JOG
Bit 16 Collision monitoring for tool measurement
Bit 17 For tool measurement, number of repeat measurements if the probe does not switch
Bit 18 Measuring feedrate for tool measurement
Bit 19 Retraction velocity from the measuring point for tool measurement
7.9.2 Manufacturer and user cycle CUST_MEACYC.SPF
Function
The CUST_MEACYC.SPF is part of the measuring cycle functionality. It is called in every
measuring cycle before and
after executing the measurement task. The CUST_MEACYC.SPF
acts in the same way when measuring in the JOG mode and measuring in the AUTOMATIC
mode.
Configuring cycles
7.9 Measuring cycles and measurement functions
SINUMERIK Operate
Commissioning Manual, 10/2015, 6FC5397-3DP40-5BA3 173
