6. Press the "Details" softkey to hide the detailed display.
7. Press the "Return" softkey in order to exit the "TCP/IP Diagnostics" win‐
dow and return to the "PROFINET/PROFIBUS Diagnostics" window.
4.4.2 TCP/IP diagnostics and configuration
The configuration of the
network interfaces is displayed in the "TCP/IP Configuration" window.
Service
You use the service interface X127 for start-up and diagnostics.
A PG/PC communicates with the control via this interface as peer-to-peer. The IP address
192.168.215.1 is permanently set for the service interface.
Company network
The company network is used, for example, to access the network drives.
A PPU is connected to the company network via Ethernet interface X130.
Availability of the network connections
Network adapter connection
White Network cable inserted
Red Network cable not inserted
Availability
The availability describes the percentage of faulty packages compared to all the sent and
received packages.
Problems in the company
network or the settling time during the start-up can cause fluctuations
in the availability.
Green Greater than 95%
Yellow 50 - 95%
Red Less than 50%
Details of the network connections
● Computer name
The computer name of the control.
● DNS name
The name of the network adapter as stored in the DNS (Domain Name Service) server.
● MAC address
The physical address of the network adapter.
Configuring the network
4.4 Station-related network diagnostics
SINUMERIK Operate
Commissioning Manual, 10/2015, 6FC5397-3DP40-5BA3 41
