Extension in manufacturer cycle CUST_832.SPF
The following labels are provided in manufacturing cycle CUST_832.spf for Top Surface:
31 _M_TOP_SURFACE_FINISH:
Finishing with COMPSURF
32 _M_TOP_SURFACE_SEMIFINISH:
Semi-finishing with COMPSURF
33 _M_TOP_SURFACE_ROUGH:
Roughing with COMPSURF
The following G commands are programmed in labels 31 to 33:
SOFT
COMPSURF
G645
FIFOCTRL
UPATH
;FFWON
Depending on the machining type used, the following G commands of G group 59 are
programmed:
DYNFINISH
DYNSEMIFIN
DYNROUGH
7.9
Measuring cycles and measurement functions
7.9.1 Measuring cycles and measurement functions, general
Requirement
Two types of electronic probes are used for measuring:
● Probe to measure the workpiece
●
Probe to measure the tool
The electronic probe must be connected on the PPU or the NX module.
The electronic probe is called probe in the following document
Setting the switching behavior
You set the electrical polarity of the connected probe using the following general machine data:
MD13200 $MN_MEAS_PROBE_LOW_ACTIVE Polarity change of the probe
= 0 Probe in the non-deflected state, 0 V default value
Probe in the deflected state, 24 V
= 1 Probe in the non-deflected state, 24 V
Probe in the deflected state, 0 V
Configuring cycles
7.9 Measuring cycles and measurement functions
SINUMERIK Operate
170 Commissioning Manual, 10/2015, 6FC5397-3DP40-5BA3
