Parameters Meaning
nPlane Plane
nTechnology Technology
The
following constants are defined for the SlStep‐
Technology enumeration type:
● SL_STEP_NO_TECHNOLOGY
● SL_STEP_MILLING
● SL_STEP_TURNING
● SL_STEP_SURFACE_GRINDING
● SL_STEP_CIRCULAR_GRINDING
void viewSceneSlot ( const QString& rsFileName, const QString& rsScene, const QString&
rsAnimationScene )
A simplified form of the viewSceneSlot method with which the X3D Viewer can be instructed
to load and display the rsScene static scene and/or the rsAnimationSzene animated scene
from the rsFileName file.
Parameters Meaning
rsFileName Name of the file that contains the scenes to be
displayed.
rsScene Name of the static scene.
rsAnimationScene Name of the animated scene.
C.5.5 Libraries
In
order to be able to apply the X3D Viewer in your own projects, the list of library dependencies
must be extended by the 'slx3dviewer.lib' entry.
C.5.6 Implementation example
You will find an implementation example in the package Create MyHMI/3GL under \examples
\GUIFrameWork\SlExGuiX3D.
C.5.7 Machine data
Display MD 9104 $MM_ANIMATION_TIME_DELAY
Time delay in seconds until the animation is started for help screens. The setting does not
apply to help screens that are only animated.
The setting applies globally to all animations of SINUMERIK Operate.
Animated elements
C.5 Display in Create MyHMI /3GL
SINUMERIK Integrate Run MyScreens
Programming Manual, 10/2015, 6FC5397-3DP40-5BA3 225
