9.2.13 Configuring the "Details" window
<DETAILSCONFIGURATION> tag
In the tag <DETAILSCONFIGURATION>,
you can make the settings for the "Detail" window:
Entries Meaning
ShowToolNumber The tool number is displayed in the upper right field of the "Detail" window.
UseAxisNameInLength The tool length is displayed with axis identifiers, for example, Length X
instead of Length 1.
If no data is specified, then the setting is taken from the tool lists.
ShowBaseLength The basic length is displayed in the "Detail" window (AdaptLength1,
AdaptLength2 and AdaptLength3).
If no data is specified, then the setting is taken from the tool lists.
ShowYAxis The Y axis is displayed in the "Detail" window.
If no data is specified, then the setting is taken from the tool lists.
AutoDisplayAxisEnabled Several components of the tool length are displayed, even if only one
tool length is displayed in the tool list.
Example
<DETAILSCONFIGURATION>
<ShowToolNumber value="true" type="bool" />
</DETAILSCONFIGURATION>
9.2.14
Assignment of TO units and toolholders to channels
Preassignment of TO units and toolholders to channels
The assignment between TO unit and channel is made via the MD28085 machine data. The
assignment between toolholder and channel is made via the MD20124 machine data (only
for TE822).
Each channel is assigned its own dedicated TO unit.
●
Channel 1
MD28085 $MC_MM_LINK_TOA_UNIT
Assigns TO unit to a channel (SRAM)
= 1 The channel is assigned TO unit 1.
● Channel 2
MD28085 $MC_MM_LINK_TOA_UNIT Assigns TO unit to a channel (SRAM)
= 2 The channel is assigned TO unit 2.
Tool management
9.2 Configuring the user interface
SINUMERIK Operate
266 Commissioning Manual, 10/2015, 6FC5397-3DP40-5BA3
