If the time has expired Defines the period which after expiry, the recording is exited.
If the memory is full The recording is terminated when the specified data volume
(KB) is reached.
10.4.2.3 Trace options
You define the following properties of a trace session in the "Trace - Options" window.
● Setting the graphic window
– Displaying main grid lines: You define whether a horizontal grid is displayed and in which
color.
– Displaying grid sub-lines: You define whether a vertical grid should be displayed and in
which color.
– Background: You select the background color of the graphic window.
● Defining storage options
– Activate the "Confirm file overwrite" checkbox in order to receive a confirmation prompt
each time a trace session is to be overwritten. If the checkbox is deactivated, the trace
session is overwritten without a confirmation prompt.
– Activate the "Save file in both formats" checkbox in order to also save the data as a csv
file (Page 361) in addition to the xml session file. The file in csv format cannot be
imported again.
Procedure
1. You are in the "Select Variables for Trace: ..." window and a trace ses‐
sion has been selected.
2. Press the "Options" softkey.
The "Trace - Options" window opens.
3. Select the desired settings and press the "OK" softkey in order to accept
the settings.
10.4.3 Starting the trace
In the "Trace" window,
you obtain the curve with the data of the variables selected for a trace
session.
The diagram comprises two Cartesian coordinates:
● Time axis
The horizontal x axis supplies the time values.
● Value axis
The vertical y axis displays the resolution fineness (amplitude).
Service and diagnostics
10.4 Trace
SINUMERIK Operate
350 Commissioning Manual, 10/2015, 6FC5397-3DP40-5BA3
