Access levels for window "Internal Data"
MD51198 $MNS_ACCESS_READ_TM_ALL_PARAM Protection level TOOLMAN details -
Read internal data.
Depending on the machine data, the
"Internal Data" softkey is either hidden
or displayed.
MD51215 $MNS_ACCESS_WRITE_TM_ALL_PARAM Access level TOOLMAN details - Write
internal data.
Access levels for certain functions of the tool management
MD51216 $MNS_ACCESS_TM_TOOL_CREATE Access level, TM, create tool.
MD51217 $MNS_ACCESS_TM_TOOL_DELETE Access level, TM, delete tool.
MD51218 $MNS_ACCESS_TM_TOOL_LOAD Access level, TM, load tool.
MD51219 $MNS_ACCESS_TM_TOOL_UNLOAD Access level, TM, unload tool.
MD51220 $MNS_ACCESS_TM_TOOL_MOVE Access level, TM, move tool.
MD51221 $MNS_ACCESS_TM_TOOL_REACTIVATE Access level, TM, reactivate tool.
MD51222 $MNS_ACCESS_TM_TOOL_MEASURE Access level, TM, measure tool.
MD51223 $MNS_ACCESS_TM_TOOLEDGE_CREATE Access level, TM, create tool cutting
edge.
MD51224 $MNS_ACCESS_TM_TOOLEDGE_DELETE Access level, TM, delete tool cutting
edge.
MD51225 $MNS_ACCESS_TM_MAGAZINE_POS Access level, TM, position magazine.
9.1.3 Additional settings
Additional settings
You can enable further
functions on the user interface via the following machine data / setting
data:
MD52270 $MCS_TM_FUNCTION_MASK
Bit 0 Creating a tool at the magazine location is not permitted.
Bit 1 Load/unload lock if the machine is not in the reset state.
Bit 2 Load/unload lock for EMERGENCY OFF.
Bit 3 Loading/unloading or relocating tool in/out of spindle locked.
Bit 4 Tool loaded directly into spindle.
Bit 5 Using the grinding configuration file.
Bit 6 Relocating a tool in/out of spindle is permitted despite lock (see bit 3).
Bit 7 Tool is created using the number.
Bit 8 Hide tool relocation.
Bit 9 Hide magazine positioning.
Bit 10 Reactivate tool with magazine positioning.
Tool management
9.1 Machine data for tool management
SINUMERIK Operate
224 Commissioning Manual, 10/2015, 6FC5397-3DP40-5BA3
