HS2=("\\image1.png") ; Assign a softkey to the graphic

HS3=("Exit")

HS4=(["Confirm","\\sk_ok.png"],PA0,TP1) ; Softkey with text and graphic, Text="Confirm", Im-

age="sk_ok.png",

Alignment of the softkey image: Left,

text is aligned to the image

VS1=("sub screen form")

VS2=($85011, ac7, se2) ; Define softkey VS2, assign the text from the lan-

guage file, protection level 1, and the status "disa-

bled"

VS3=("Cancel", ac1, se3) ; Define softkey VS3, assign the label "Cancel", pro-

tection level 1 and the status "highlighted"

VS4=("OK", ac6, se1) ; Define softkey VS4, assign the label "OK", protec-

tion level 6 and the status "visible"

VS5=(SOFTKEY_CANCEL,,se1) ; Define cancel standard softkey VS5 and assign the

status "visible"

VS6=(SOFTKEY_OK,,se1) ; Define OK standard softkey VS6 and assign the status

"visible"

VS7=(["\\image1.png","OEM text"],,se1) ; Define softkey VS7, assign an image, assign the la-

bel "OEM Text" and the status "visible"

VS8=(["\\image1.png",$83533],,se1) ; Define softkey VS8, assign an image, assign text

from language file and the status "visible"

PRESS(HS1) ; Method start identifier

HS1.st="Calculate" ; Assign a label text to the softkey

...

END_PRESS ; Method end identifier

PRESS(RECALL) ; Method start identifier

LM("Screen form21") ; Load dialog

END_PRESS ; Method end identifier

//END ; End identifier of softkey menu

4.2.1 Changing softkey properties during runtime

Description

The

softkey properties Text, Access Level and Status can be changed in the methods during

runtime.

Dialogs

4.2 Defining softkey menus

SINUMERIK Integrate Run MyScreens

Programming Manual, 10/2015, 6FC5397-3DP40-5BA3 53
