7. Connect by double-clicking the "Double-click to update" icon. If the connection is made
successfully, the icon will be displayed with a green border:
Figure 1-5 Online connection
If
a
connection
is
not established, check the settings under "Network connections" → "Local
Area Connection".
8. Confirm with "OK" and repeat Step 7.
1.6.3 How to communicate with the control via Access MyMachine
Connection options
The following options are available for "Access MyMachine" to establish a connection to the
control.
● Direct connection (peer-to-peer)
● Network connection
The current status of the connection is displayed at the bottom in the status bar of Access
MyMachine.
Meaning of the buttons:
Connect
Disconnect
Remote control
Scope of delivery and requirements
1.6 Communication with the control
CNC commissioning
26 Commissioning Manual, 10/2015, 6FC5397-3DP40-5BA3
